Description
2-wire Power Loop
An extra AC power supply is not necessary. 2-wire loop powered performance allows direct connection to DCS I/O card possible, allowing for real cost reductions.
- Reduced CAPEX and OPEX on site.
- Power consumption reduced by 40% compared to a typical 4-wire magnetic flowmeter.
- Annual CO2 emissions can be reduced from approximately 60 kg to 1.2 kg (compared to a standard 4-wire magnetic flowmeter).
Dual Frequency Performance
Yokogawa’s unique and advanced excitation method, “Dual Frequency Excitation,” achieves stable measurement, zero stability and quick response times. The exclusive technology for stable and reliable measurement on your site.
Noise Reduction Technology
Flow noise reduction is further achieved by incorporating smooth mirror finished PFA liners and special surface finished electrodes. This is further enhanced with aligned super high density coils that generate a stronger magnetic field.
SIL2 Certified
Yokogawa believes safety should not be an option; it should be standard in all modern products. AXR is the first 2-wire magmeter of SIL2 Safety Integrity Level (IEC 61508) certified. AXR is capable of SIL2 single use and SIL3 redundant use, as standard.
Parameter Operation
AXR has magnet switches for parameter setting. Users can access the functions without removing the case cover in hazardous, humid, and dusty environments.
Adhesion Diagnostic Level Function
The electrode is one of the most important parts of a magnetic flow meter. Only ADMAG flow meters have “Adhesion Diagnostic Level Function”. It diagnoses the condition of electrode surface and indicates the adhesion/coating in 4 levels. Users can change the detection level (threshold) depending on each individual process condition. This allows for predictive maintenance and reduced operating costs.
Alarm Indication
ADMAG AXR employs a full-dot matrix LCD indicator. It can display up to 3 lines as required by the user and is available in multiple languages. If an alarm is triggered, a clear message is displayed along with a solution.
High Accuracy
The ADMAG AXR performs 0.5% of rate under normal flow rate conditions.
