Description

Benefits

Zero Up and Zero Down installation capabilities
Lining specifically for drinking water applications requiring special approvals
Increased low flow accuracy for water leak detection (NBR or EPDM lining)
Suitable for underground installation and permanent immersion (IP68) or underwater installation
Integrated grounding electrodes – no grounding rings required for many applications
Short delivery time
SITRANS FM portfolio – our integrated platform enables the flexible use of the transmitter MAG 5000 / 6000 for all products (MAG 5100 / 3100/1100):
• Unique SensorProm technology – stores critical, sensor-specific data and passes it to the transmitter. This allows a simple, flexible commissioning of the sensor.
• Plug & Play – allows easy on-site replacement and commissioning of the transmitter in just minutes
• “Hot swapable” – exchangeable during operation
• Mounting flexibility – compact or separate installation possible
• Validated calibration ensures accurate flow measurement. Each Siemens flowmeter is calibrated in facilities that are individually accredited to ISO / IEC 17025.
• Service and diagnostics – Designed for MAG on-site verification with traceable certification. Regular calibration of the SITRANS FM Verificator ensures accuracy in the field.

Meassuring range	0 to 10 m/s
Nominal sizes	From DN 15 to DN 2000 (1″ to 78″)
Accuracy	0.2 % ±2.5 mm/s
Operating pressure	Max. 16 bar (Max. 150 psi)
Ambient temperature	From -40 to 70 °C (-40 to 158 °F)
Medium tempreature	From -10 to 70 °C (14 to 158 °F)
Liners	EPDM NBR hard rubber Ebonite hard rubber
Electrodes	Hastelloy C-276 Built-in grounding electrodes
Material	Carbon steel, with corrosion resistant two-component epoxy coating
Drinking water wpprovals	EPDM: WRAS, NSF/ANSI Standard 61, DVGW 270, ACS and BelgAqua NBR: NSF/ANSI Standard 61, WRAS Ebonite: WRAS
Custody transfer approvals	OILM R 49 MI-001 PTB K7.2 (Germany) BEV OE12/C040 (Austria)
General approval	MCERTS Sira Certificate No. MC080136/09
